DELUXE MAGNETIC STIRRERS

These deluxe magnetic stirrers are unique in design, totally enclosed, highly chemical resistant even to acid and alkali. Ideal for all types of laboratory stirring applications from 500 ml to 10 liters. These magnetic stirrers give better speed regulation even at low speed. The stirring speed and heating energy is controlled by steeples speed and energy regulator.

Salient Features :

• Digital Speed Indicator for display of stirring SPEED
• PMDC motor for higher torque even at low
• Better low speed stirring even with small
• Accurate stepless speed control maintains excellent speed Stability

• Specially designed for corrosive atmosphere reducing  the chances of fumes entering the unit.

TECHNICAL DATA

MODELS                                   5MLHOX                         10 MIOX

CAPACITY  LTRS                           5                                        10

WXOXH        MM                   200X225X185                        250X250X205

HOT PLATE   WALTS                 600

STIRING           MODEL           Q-20A                                   Q-20A

PADDLE             0XLENGHT   13X50 MM                         13X50MM

SUPPLY 220-240VOLTS 50 HZ SINGLE PHASE

ELECTROMAGNETIC     STIRRERS

Electromagnetic (motor less ) stirrers are ideally suitable for titration & general lab .mixing of solution . they  incorporate superior steeples speed controller to control the speed from 100 to 650 RPM.THE units have features of reverse spin direction mode, which can be adjustable from 30 seconds to 4 minutes.in case stirring paddle files out, it is automatically caught back with the help of unique catch back features. Different modes with multiple 2,4, &6 stirring points also available. supplied with Tefflon paddle 9×25 mm. (Q-19).

salient features :

no moving parts or motor.

light weight, compact size & portable

reverse control provides automatic change of direction

accurate stepless speed control maintains excellent speed stability despite viscosity or volume changes.

stirring capacity up to 1000ml per stirring point

technical data

model no.              1 ems                2 ems                   4 ems             g ems

stirring points                                     2                            4                    6

WXDXH (MM)  170X175X60 270X165X60 270X290X60 400X275X60

SUPPLY 220-240 VOLTS 50 Hz SINGLE PHASE
